Yaskawa SGD7S-180A00A002 | Yaskawa Driver Module

Brand: Yaskawa

Model: SGD7S-180A00A002

Product size with packaging: 28*24*18cm

Product weight with package: 3.2kg

Series: SGD7S

Product type: Servo drive

Origin: Japan

The following is a detailed introduction to the driver module and the solution:

Model and specification: SGD7S-180A00A002 is a servo driver module produced by Yaskawa Corporation, suitable for three-phase input, voltage range is 200-240V, frequency is 50/60Hz, main control input rated current is 10A. In terms of output, single-phase output voltage is 200-240V, frequency is 50/60Hz, rated current is 0.25A; Three-phase output voltage range is 0-240V, frequency range is 0-500Hz, rated current is 5A, rated power is 2kW.

Alarm code 710: indicates that the motor is overloaded, that is, the motor bears too much load during operation, which may lead to equipment performance degradation or downtime.

Solution:

1. Change the mechanism or acceleration and deceleration mechanism: Consider replacing the mechanism of the equipment or increasing the deceleration device to reduce the load borne by the motor and reduce the risk of overload.

2. Replace the motor: If the motor overload is serious and cannot be solved by changing the mechanism, you need to consider replacing the motor and select the motor model suitable for the load requirements.

3. Troubleshooting sequence:

Check whether the load is really too large.

Check whether the power line of the motor is broken or connected incorrectly to ensure that the connection is correct and reliable.

Check whether the position encoder (PG) line is disconnected and ensure that the position feedback signal is normal.

Check the position encoder (PG) for damage and replace it in time.

If all the above checks are normal, the servo drive itself may be faulty and needs to be replaced or repaired.

Environmental adaptability: The driver module can work normally in the ambient temperature range of -5°C to 55°C, adapting to different working environments and temperature conditions.

Manufacturing information: The driver module is manufactured by Yaskawa Electric Co., LTD., the product quality is reliable, has high performance and stability.

To sum up, Yaskawa drive module SGD7S-180A00A002 is suitable for a variety of industrial applications, but in the occurrence of alarm code 710, it is necessary to pay attention to the load of the motor and check it step by step in the order of troubleshooting to ensure the normal operation and safety of the equipment.
