Product category: Drive
Brand: AB Rockwell
Country of origin: USA
Size: 26.5*20.5*5.5cm
Weight: 2kg
Power: 1000
Rated voltage: 220
Product certification: 3C certification
Speed response frequency: 100
Applicable motor: general purpose
Allen-Bradley 2198-H015-ERS is a Kinetix 5500 servo drive. Built on an integrated architecture mid-range system, the Kinetix 5500 servo drive product family, including the 2198-H015-ERS, features integrated Ethernet I/P safety and motion capabilities to drive servo and induction motors, with digital feedback for real-time monitoring and performance evaluation of the system.
The 2198-H015-ERS is designed to operate in a variety of input supply voltage ranges, such as 195-264Vrms, single-phase 240VAC nominal voltage, 195-264Vrms, three-phase 240VAC nominal voltage and 324... 528Vrms, three-phase 480VAC nominal voltage, at 324-528Vrms, three-phase power supply input current requirements of 5.2A, at 195-264VAC single-phase voltage, input current requirements of 3.4A. The servo driver has A short circuit current rating of 200,000 A symmetric,
The output characteristics of the 2198-H015-ERS include a PWM frequency of 4KH2, a maximum speed loop frequency of 300 Hz, and a current loop of 1000 Hz. The servo driver has a continuous output current (rms) of 5.0A, a continuous output current (0-pk) of 7.1A, a peak output current (rms) of 12.5A, and a peak output current (0-pk) of 17.7A. 2198-H015-ERS in 195... 264Vrms with 1.0 KW continuous output current, single phase; 195.. 1.5KW at 264Vrms, three-phase; 324.. 3.2kW at 528vrms, three phases.
Integration can be achieved using a built-in dual Ethernet communication interface, which can be used for both linear and ring tows, and these Ethernet ports also allow the implementation of integrated security and motion control.
The 2198-H015-ERS drive is a servo motor device that is part of the Kinetix 5500 servo drive manufactured by Allen-Bradley. Servo motor drivers are electronic amplifiers that meet the needs of industrial applications. Servo motor drives help monitor feedback signals and adjust deviations in the system. It takes the input signal from the control system, amplifies the signal, and then transmits the current to the co-operating motor to produce a motion proportional to the command signal. The 2198-H015-ERS inverter is classified as Rack 2, which is completely hardwired for safety purposes, and the servo motor equipment is equipped with a feedback device to convey real-time information to the user about the health and status of the system. The input voltage of the servo motor supports single-phase operation of 190 to 264 volts RMS and three-phase operation of 324 to 528 volts RMS. The simultaneous motor unit has a peak output current of 12.5 amps, it can also continuously output current in the peak current range of 0 to 7.1 amps, and nominal drive voltages use 240 volts single-phase and 240 to 480 volts three-phase current voltages.
The 2198-H015-ERS inverter is equipped with two (2) Ethernet communication ports and can be used in linear and device level ring (DLR) topologies. The size of the motor unit is 2.16 "x8.90" x10.43 ". The compact size of the motor equipment makes it easy to set up servo motors in small factories. The servo motor weighs 5 pounds and consists of a controller, motor, drive and feedback system. Water flow.
The 2198-H015-ERS is designed to be cost-effective and consume less power than other motor drivers in the same service. The 2198-H015-ERS frequency converter must be housed in a grounded structural housing that provides the level of protection required by the IEC 529 standard, and the housing also helps the drive comply with UL and CE requirements.
