The B&R 8V1090.00-2 is a powerful ACOPOS servo drive with a modular mechanical design and multiple integrated features that provide an efficient motion control solution for industrial automation applications.
Brand: B&R
Model: 8V1090.00-2
Product size: 37.5*24.5*7cm Rated voltage: 400-480V
Weight: 4.4kg Power: 4kw
Product type: Drive
Place of origin: Austria
Key features and functions
Modular design
Plug-in module: Supports four slots for installing various plug-in modules to achieve flexible system configuration.
Use plug-in connectors for all connections: easy and quick connection and removal.
Integrated function
Line filter: Integrated line filter, effectively reduce electromagnetic interference, improve system stability.
Brake resistor: Built-in brake resistor for fast braking and energy feedback.
Electronic safety restart interlock: built-in electronic safety restart interlock function to ensure the safe operation of the equipment.
Electrical parameters and protection functions
Main power connection: Support TT and TN network configuration, voltage range is 3-phase 400VAC to 480VAC, frequency 50/60Hz.
DC bus connection: 470µF DC bus capacitance for a maximum continuous power consumption of 11.19 kW.
Motor connection and control
Motor connection: Supports 1 motor connection with continuous current of 8.8 Aeff and maximum peak current of 24 Aeff.
Motor continuous current derating: automatically adjusts the continuous current according to the ambient temperature and altitude to ensure the stability and safety of the system.
Input/output and protection functions
Limit switches and reference inputs: Three limit switches and reference inputs are supported for position feedback and control.
Protection function: overload, short circuit and ground fault protection, to ensure the safety of equipment and personnel.
Environmental adaptability and mechanical properties
Installation direction: Vertical suspension and horizontal installation but not horizontal installation.
Operating temperature range: normal operation in 5°C to 40°C, up to 55°C, suitable for a variety of working environments.
Mechanical dimensions: width 70.5mm, height 375mm, depth 235.5mm, weight about 4.4kg, suitable for all kinds of installation space.
B&r 8V1090.00-2 Servo driver is a versatile and stable control module for a wide range of industrial automation applications, providing efficient and reliable motion control and protection for equipment.
