IFM PM1707 Flush Pressure Sensor | -0.05 to 1 bar 4-20mA IO-Link G1 Aseptoflex

The IFM PM1707 is a flush pressure sensor for process applications with -0.05 to 1 bar range, 4-20mA scalable analog output plus IO-Link, G1 Aseptoflex process connection, and IP67/IP68/IP69K rating for hygienic environments.

Model Number:IFM PM1707

Product Image

Submit your inquiry and we'll respond within 24 hours

100k+ Parts

Extensive Inventory

Warranty Coverage

New parts: 1-Year | Used: 3-Month

17+ Years

Industry Experience

Fast Shipping

Ships Within 48 Hours

The IFM PM1707 belongs to the PM17 series of flush pressure transmitters designed specifically for hygienic process technology, featuring a dead-space-free Aseptoflex Vario G1 threaded connection with ceramic diaphragm (99.9% Al2O3) and Ra <0.4µm surface finish for CIP/SIP cleaning in food, beverage, and pharmaceutical applications. It measures relative pressure from -0.05 to 1 bar (-50 to 1000 mbar) with hydrostatic piezoresistive technology, delivering configurable 4-20mA 2-wire analog output (scalable ASP/AEP) alongside IO-Link COM2 digital interface for diagnostics, temperature monitoring, and parameter setting.

The stainless steel (316L) housing withstands media up to 150°C and bursting pressure of 30 bar, with protection class IP67/IP68/IP69K for washdown resistance. It includes reverse polarity protection, short-circuit/overload protection, and integrated watchdog, supporting process data transmission every 3.2ms with MTTF >323 years for reliable 24/7 operation in demanding sanitary environments.

Technical Specifications

Parameter	Specification
Model	PM1707
Type	Flush pressure sensor/transmitter
Measuring Range	-0.05…1 bar (-50…1000 mbar / -0.73…14.5 psi)
Process Connection	G1 external thread Aseptoflex Vario
Output Signals	4-20mA analog (scalable) + 1x IO-Link digital
Supply Voltage	18-30V DC
Accuracy	<±0.2% span (characteristics); <±0.1% repeatability
Response Time	30ms analog; 7ms IO-Link
Medium Temperature	-25°C to +150°C
Ambient Temperature	-25°C to +80°C
Burst Pressure	30 bar
Protection Rating	IP67 / IP68 / IP69K
Electrical Connection	M12 connector (A-coded, gold-plated)
Wetted Materials	Ceramic (99.9% Al2O3), SS 316L/1.4435, PTFE
Weight	281.5-314g
Dimensions	Ø30.2 x 111 mm
