Detailed Description:
-
Large HD Display: Features a 15-inch widescreen TFT color LCD display, providing a high-resolution visual experience ideal for displaying large amounts of information and complex process screens on a single display.
-
Operation: Utilizes a projected capacitive touchscreen, supporting multi-touch and gestures (e.g., zoom, swipe), delivering an intuitive and responsive operation experience. The front panel has a protection rating of IP65, making it dust-tight and water-resistant.
-
Outstanding Performance: Based on a powerful processor and large user memory, it can smoothly run complex visualization projects and quickly process large volumes of data and graphical elements.
-
Rich Communication Interfaces: Integrates 2 PROFINET interfaces supporting Media Redundancy Protocol (MRP) for network reliability. Provides 4 USB 2.0 ports for easy connection of peripherals, project transfer, or using USB drives for data logging. Some models may include additional interfaces (e.g., COM port).
-
Advanced Features: Supports a comprehensive alarm system, multi-level user management (up to 2000 users), powerful recipe management, and data logging functions. Built-in PDF/Word/Excel viewer allows viewing technical documents directly on the panel.
-
Project Configuration: Configured and programmed using WinCC Comfort/Advanced or higher editions within TIA Portal.
-
Application Scenarios: Widely used in large process industries (e.g., chemicals, water treatment), high-end manufacturing equipment, central control rooms, production line monitoring stations, and other scenarios requiring large screens and high-performance operator interfaces.
Key Specifications:
| Parameter | Details |
|---|---|
| Model | 6AV2123-2GB03-0AX0 |
| Series/Model | SIMATIC HMI Comfort Panel TP1500 Comfort |
| Display | 15-inch TFT Color LCD, Resolution 1366 x 768 (HD)， Widescreen |
| Colors | 16.7 M Colors (True Color) |
| Operation | Projected Capacitive Touchscreen (supports multi-touch & gestures) |
| Communication Interfaces | 2x PROFINET (RJ45, supports MRP), 4x USB 2.0 |
| User Management | Up to 2000 users |
| Alarms & Recipes | Comprehensive alarm system, powerful recipe management |
| Data Logging | Supports data logging function |
| Built-in Viewers | PDF/Word/Excel Viewer |
| Power Supply | 24 V DC |
| Protection Rating (Front) | IP65 / NEMA 4X |
| Mounting | Panel Cut-out Mounting / VESA Arm Mounting (optional) |
| Configuration Software | TIA Portal WinCC (Comfort/Advanced or higher) |
| Dimensions (W x H x D) | Approx. 397 mm x 297 mm x 53 mm |
| Cut-out Dimensions (W x H) | Approx. 378 mm x 277 mm |
