Detailed Description:
-
High-Precision Analog Inputs: The module provides 4 analog input channels with a high resolution of 15 bits (including sign), enabling precise measurement of minute signal changes.
-
Flexible Measuring Ranges: It supports a wide range of signal types, including voltage inputs (e.g., ±10V, 0-10V, ±5V, 1-5V) and current inputs (e.g., 0-20 mA, 4-20 mA), making it compatible with various industrial sensors.
-
Simplified System Integration: The module connects directly to the S7-200 SMART CPU or other expansion modules via a right-side bus connector. It requires no separate power supply module as it is powered via the system bus, simplifying installation and wiring.
-
Electrical Isolation: The analog input channels are electrically isolated (500 V AC) from the PLC’s system logic, effectively enhancing system noise immunity and safety.
-
Plug-and-Play Configuration: The module can be easily configured using Siemens STEP 7-Micro/WIN SMART programming software, requiring no complex setup, with automatic I/O address assignment.
-
Compact and Rugged Design: Featuring the standard compact dimensions of S7-200 SMART modules, it is suitable for installation in tight control cabinets and offers good adaptability to industrial environments.
Key Specifications:
| Parameter | Details |
|---|---|
| Model | 6ES7 241-1CH30-1XB0 |
| Series | SIMATIC S7-200 SMART |
| Module Type | Analog Input Module (EM AE04) |
| Number of Input Channels | 4 channels |
| Input Signal Ranges | Voltage: ±10V, 0 to 10V, 0 to 5V, ±5V, ±2.5V, 1 to 5V; Current: 0 to 20 mA, 4 to 20 mA |
| Resolution | 15 bits (including sign) |
| Basic Accuracy (25°C) | ±0.3% of full scale |
| Electrical Isolation | Isolation between channels and system (500 V AC) |
| Power Consumption (Backplane Bus 5 V DC) | 60 mA |
| Sensor Supply (L+) | 24 V DC (20.4 to 28.8 V DC) |
| Maximum Wiring Length | 100 m (shielded twisted pair) |
| Dimensions (W x H x D) | 45 mm x 100 mm x 81 mm |
| Required Configuration Software | STEP 7-Micro/WIN SMART |
