Detailed Description:
-
Compact Front-End Expansion: The signal board plugs directly into a dedicated slot on the front of an S7-200 SMART CPU, requiring no additional rail width, maintaining a compact control cabinet layout. It provides great convenience for users needing to add analog input points late in a project or in space-constrained situations.
-
Input Characteristics: Provides 2 independent analog input channels. Each channel can be configured for the following industrial standard signals:
-
Voltage Input: ±10 V
-
Current Input: 0 – 20 mA, 4 – 20 mA
-
-
Basic Accuracy & Resolution: The module offers basic accuracy and resolution sufficient for most process measurement applications, such as connecting temperature transmitters, pressure sensors, or flow meters.
-
Flexible Addressing: The I/O addresses of the signal board are automatically assigned by the system and integrated into the CPU’s I/O system, allowing for easy configuration in STEP 7-Micro/WIN SMART software.
-
Application Scenarios: Particularly suitable for applications requiring the addition of a small number of analog measurement points in space-constrained environments. Examples include adding a temperature or pressure monitoring channel to an existing CPU.
Key Specifications:
| Parameter | Details |
|---|---|
| Model | 6ES7274-1XF30-0XA0 |
| Series | SIMATIC S7-200 SMART (Signal Board) |
| Module Type | Analog Input Signal Board (SB) |
| Number of Channels | 2 |
| Input Type | Voltage or Current |
| Voltage Input Range | ±10 V |
| Current Input Range | 0 – 20 mA, 4 – 20 mA |
| Resolution | Specific value requires manual (typically 12-bit or higher) |
| Accuracy | Meets general industrial application requirements |
| Power Supply | Powered via internal bus from the connected CPU |
| Mounting | Direct plug-in into the signal board slot on the front of an S7-200 SMART CPU |
| Required Programming Software | STEP 7-Micro/WIN SMART |
