Detailed Description:
-
Standardized I/O Interface: This module provides a certain number of digital input points and digital output points, typically conforming to FANUC’s standard I/O signal specifications (e.g., +24V DC level). It connects to external machine wiring via dedicated connectors or terminal blocks.
-
Modular System Integration: Designed for installation on a FANUC αi Series CNC I/O Unit baseboard or as an I/O Link slave module. It communicates with the CNC main controller via the high-speed I/O Link bus or internal backplane bus, ensuring fast and reliable signal transmission.
-
Reliable Industrial Design: Utilizes industrial-grade electronic components and a compact structural design, featuring strong noise immunity and fast response times. The module is typically equipped with LED indicators that visually display the status (ON/OFF) of each I/O point, facilitating on-site debugging and fault diagnosis.
-
Flexible Configuration and Application: The number and type (input/output) of I/O points are determined by its specific model and the unit it belongs to. The address and function of this module can be flexibly configured via the CNC system parameters (e.g., PMC parameters) to suit the I/O requirements of different machine tools.
-
Wide Range of Applications: As a fundamental component of the CNC system, it is used to control various auxiliary functions of the machine tool, such as: tool magazine/turret control, coolant/lubrication start/stop, workpiece clamping/unclamping, door lock control, indicator lights, and alarm displays.
Key Specifications:
| Parameter | Details / Typical Features |
|---|---|
| Model | A03B-0819-C154 |
| Series | FANUC αi Series |
| Module Type | I/O Unit Module (Digital Input/Output Module) |
| Compatible System | For I/O Units of FANUC Series 0i-MD, 0i-Mate-MD, 30i/31i/32i, etc. |
| Interface Standard | +24V DC Input / +24V DC Transistor Output (common type) |
| Typical I/O Points | Specific point count requires manual (e.g., 16 inputs/16 outputs or similar combination) |
| Communication Method | Connected to CNC/PMC via I/O Link bus or internal bus |
| Power Requirement | Supplied by the I/O Unit baseboard or external +24V DC power source |
| Status Indication | Typically includes an LED status indicator for each I/O point |
| Operating Temperature | 0 ~ 55°C (consistent with CNC system environmental requirements) |
| Mounting Method | Plugs into a designated I/O Unit baseboard or module rack |
