The A06B-6079-H401 is a genuine FANUC Dynamic Brake Module (DBM) for the Alpha and ai series servo systems. Operating from 200VAC, it provides emergency stop braking by short-circuiting motor power lines. The module draws 220VA during activation and 22VA in holding state. It is compatible with ai SV 360, ai SV 180HV, ai SV 360HV, and ai SV 540HV amplifiers. Dimensions are 380 x 100 x 172 mm, weight is 5.4 kg. Essential safety component for CNC machine protection.
Key Specifications
| Catalog Number | A06B-6079-H401 |
| Product Type | Dynamic Brake Module (DBM) |
| Power Supply | 200VAC |
| Power Consumption | 220VA (activation) / 22VA (holding) |
| Max Current | 200A |
| Dimensions | 380 x 100 x 172 mm |
| Weight | 5.4 kg |
| Compatible Amplifiers | ai SV 360, ai SV 180HV, ai SV 360HV, ai SV 540HV |
| Series | FANUC Alpha / ai Series |
